Pulleys - SRKGK
Wheel: Made from break-proof, hard and tough cast Polyamide PA6 G nature, high compressed, with round rope-groove. With deep groove ball bearings. (On request we also can produce these rollers in stainless version)
Ø 30 - 360 mm
105 - 5.000 kg
-40 °C to +105 °C
Hardness: 80° +/- 3° Shore D
Hardness: 80° +/- 3° Shore D
Choose your variant
Wheel Ø (mm)30
Wheel width (mm)10
Axle Ø (mm)8
Radius (mm)3
Max. rope Ø (mm)5
Go to product table
Product information
| Description | SRKGK030/10/8/R3 |
|---|---|
| Load capacity (kg) | 130 |
| Wheel Ø (mm) | 30 |
| Outer Ø (mm) | 30 |
| Max. rope Ø (mm) | 5 |
| Axle Ø (mm) | 8 |
| Fitting length (mm) | 5 |
| Wheel width (mm) | 10 |
| Roller width (mm) | 10 |
| Radius (mm) | 3 |
| Bearing type | Ball bearings |
Ground Suitability
Suitable for:- Hard, flat, plain, without obstacles, clean, no edges or sills etc.
- Hard, flat, plain, clean, with grooves or seams.
- Smooth, flat, plain, clean.
